BYD Atto 3 Charge Spec and Overview

BYD Atto 3 Charge Spec and Overview

The BYD Atto 3 is a fully electric SUV produced by the Chinese manufacturer BYD and imported to Australia by EV Direct. It is classified as a small SUV and is built on a dedicated EV-only platform, offering advanced features such as Vehicle to Load (V2L) functionality, structural battery technology, and improved battery chemistry for enhanced fire resistance and charging efficiency.


Battery Capacity

BYD Atto 3:

  • Standard Range (SR): 49.92 kWh (gross)
  • Long Range (LR): 60.48 kWh (gross)

Energy Consumption (WLTP Test Cycle)

  • Standard Range (SR): 145 Wh/km
  • Long Range (LR): 144 Wh/km

Driving Range

  • Standard Range (SR):
    • NEDC: 410 km
    • WLTP: 345 km
  • Long Range (LR):
    • NEDC: 480 km
    • WLTP: 420 km

AC Charging Max Rates (1-phase)

  • Single-phase (7 kW max): Charging time from 0 to 100% is approximately 7 hours (SR) and 9 hours (LR).

DC Fast Charging

The BYD Atto 3 supports DC fast charging using the CCS2 connector:

  • Max DC Charging Speed:
    • Standard Range (SR): 70 kW
    • Long Range (LR): 80 kW
  • Charging from 0 to 80% in approximately 40–42 minutes

Approximate Charging Times

Charging Method Standard Range Long Range
10A Powerpoint 25 hours 30 hours
15A (Caravan Outlet) 14 hours 17 hours
32A (1-phase Home EVSE) 7 hours 9 hours
DC Fast Charging (50kW) 50 minutes 1 hour
DC Fast Charging (100+kW) 40 minutes 42 minutes

Performance

  • Max Power: 150 kW
  • Max Torque: 310 Nm
  • Acceleration (0-100 km/h): 7.3 seconds

Dimensions and Storage

  • Length: 4455 mm
  • Width (mirrors out): 1875 mm
  • Height: 1615 mm
  • Boot Volume:
    • 440 L (seats up)
    • 1340 L (seats down)

Towing Capacity

  • 750 kg braked / 750 kg unbraked

Disclaimer

The information provided above is intended as a general guide only. Specifications and charging times may vary based on several factors. Always confirm with the manufacturer for the most up-to-date information before making any purchase decisions.
